Ortofon Quintet Bronze

An Ortofon Quintet Bronze we used for a listening session at the VPI House earlier in 2025.  Has to be less than 20 hours used.

Output voltage at 1000 Hz, 5cm/sec.: 0.3 mV
Channel balance at 1 kHz: < 1.2 dB
Channel separation:
    1 kHz: > 23 dB
    15 kHz: > 15 dB
Frequency range at - 3dB: 20 - 25.000 Hz
Frequency response 20-20.000 Hz: +/- 1.5 dB
Tracking ability at 315Hz at recommended tracking force: 80 µm
Compliance, dynamic, lateral: 15 µm/mN
Stylus type: Nude Fine Line
Stylus tip radius: r/R 8/40 µm
Tracking force range: 2.1-2.5 g (21-25 mN)
Tracking force, recommended: 2.3 g (23 mN)
Tracking angle: 20°
Internal impedance, DC resistance: 5 Ohm
